Microsoft Local Administrator Password Solution – Part 1 – Deployment Considerations

LAPS is a fantastic free tool from Microsoft that manages Domain Member computer local account passwords. https://www.microsoft.com/en-us/download/details.aspx?id=46899

I have deployed LAPS for a number of Enterprise customers to use for managing their Domain Member Windows Server local Administrator account passwords.

In Part 1 of this blog series we will run through some of the prerequisite checks that I perform when asked to deploy LAPS.

Part 2 of this blog series “Accessing & Resetting Passwords”

Part 3 of this blog series “Monitoring”

Part 4 of this blog series “Auditing”

This post is written assuming that we have already read the installation instructions for LAPS. The list does not have to be done sequentially. Although this post is written with Server deployments in mind, the same considerations apply to Workstation deployments.

1. Nominate a management host

Nominate a device on which we will install the LAPS management tools. I normally do this on a management server which will eventually be used to run the LAPS GUI and Powershell module from by administrators. The device must have at least .NET 4.0 and Powershell 2.0.

This can of course be installed on workstations too. In the real world though many enterprises have management servers from which most admin tasks are done.

2. Nominate a test server

This is for testing the LAPS Client Side Extension and GPO. Recommended to be a Virtual Machine on which snapshots/checkpoints can be taken. Should be a non-critical server that we can reboot multiple times.

3. List the Distinguished Names of all Organisational Units that contain the target Member Servers

Typically customers will create an Organisational Unit branch called “Servers” under which they will store all of their server computer accounts. Sometimes there are servers elsewhere so it’s always good to check so that we can target all Servers with a GPO. Get all the servers not in the expected Organisational Unit branch.

In the code snippet, change the “*OU=Servers..” etc. to be the distinguished name of the OU under which the majority of the server computer accounts are.

$computers = Get-adcomputer -filter * -Properties *
$computers | ?{$_.operatingsystem -like "*Server*" -and `
$_.distinguishedname -notlike "*OU=Servers,DC=Domain,DC=com*"}

4. Identify accounts with ‘All Extended Rights’ permission

LAPS passwords are stored on the Active Directory computer object. To view the passwords a user must have the ‘All extended rights’ permission.

By default only SYSTEM and Domain Admins have this permission. It is rare that other users will have been added, however, we should check for anyone who already has this permission so that we do not inadvertently grant unauthorised users access to the new local admin passwords.

In step 3, we created a list of Organisational Units that contain all the Windows Servers that we will target with LAPS. We will now produce a list of users that have the ‘All Extended rights’ permission over these Organisational Units.

The LAPS Powershell module that is installed when you do a Full install of the LAPS client comes with a useful function to do this: Find-AdmPwdExtendedRights

The below script feeds the list of OUs ‘ListOfOU.txt’ in to to the function and creates a list of permission holders per OU.

Import-Module AdmPwd.PS
$list = Get-content ".ListOfOU.txt"
foreach($_ in $list){Find-AdmPwdExtendedRights -id "$_" `
-SchemaNotUpdated | select ObjectDN, `
@{Name=’ExtendedRightHolders’;Expression={[string]::join(“;”, `
($_.ExtendedRightHolders))}}}
Example output for ExtendedRightHolders

If any objects other than SYSTEM or Domain Admins appear in the ExtendedRightHolders column then these questions need to be answered:

a) do those objects still require the All Extended Rights permission?

b) are they authorised to be able to view passwords?

5. List of Security Principals that will have access to the LAPS passwords

An important discussion that needs to be had is “Who do you want to have access to local admin passwords?”

Too many organisations have nested Active Directory Security Groups that have inadvertently given junior IT staff Domain Admin rights. This is an ideal time to review this within your organisation or with your customer.

You can grant additional security groups the “All Extended Rights” attribute so that they do not need to have Domain Admin rights.

6. Reboot Schedule

Many Enterprises do not use SCCM to manage their Servers. Another way to deploy the LAPS installer is using Group Policy Software Installation. A draw back of this is that the client machine needs to restart in order for LAPS to install during startup.

To minimise disruption, it may be beneficial to apply the Group Policy at the start of the monthly Windows Security updates schedule and take advantage of the already agreed reboot schedules for servers.

7. Active Directory Replication

One part of deploying LAPS is extending the Active Directory Schema to add the password and password expiration date attributes to computer objects. This relies on AD replication being functional.

We can save ourselves a lot of headache during a Change Request window if we check AD replication health prior to the deployment

repadmin /replsummary
repadmin /replsummary command output

In the green box is the largest time since the last replication for all links on the listed outbound (top) or inbound (bottom) server. If any of these are in multiples of hours then there may be a replication problem.

In the pink box; if there are any failures then there is definitely a replication problem.

We must resolve issues with AD replication before we start implementing LAPS.

8. Identify Read Only Domain Controllers

The two attributes that are added when LAPS extends the Active Directory schema are:

ms-Mcs-AdmPwdStores the password in clear text
ms-Mcs-AdmPwdExpirationTimeStores the time to reset the password

By default the ms-Mcs-AdmPwd attribute is on the Filtered Attribute Set for Read Only Domain Controllers. This means that it is not replicated to RODCs. IT will not be able to retrieve LAPS passwords from the RODC.

There is logic to this, RODCs are typically located in branch locations classed as insecure. They may be behind a locked door but that door could be cupboard on the ground floor and is accessed by many non-IT staff. It must be assumed that that the RODC may one day be stolen and so we want to minimise the impact should this occur.

Do we really want the RODC to store all of the local admin passwords for all of the Servers on the network?

Nevertheless, there may be a need to replicate this attribute to RODCs. Russell Smith has an excellent blog post on how to do this: https://www.petri.com/modify-the-read-only-domain-controller-filtered-attribute-set-using-adsi-edit

To identify if any RODCs exist in the domain, run the below command:

Get-ADDomainController -Filter {IsReadOnly -eq $true}

9. Schema Admin Rights

To be able to extent the Active Directory Schema we need Schema Admin Rights. In a tightly controlled environment we need to get the request for these rights in early. No Schema Admin, no LAPS.

11. Name of Local Administrator account

Some organisations have multiple local admin accounts on a server.

  • You can only manage one account per server per policy.
  • One device can only be managed by one policy.

We should look to reduce the number of local admin accounts in use on the estate in favour of Domain User and Service Accounts with Role Based Access Control. A single local admin account can meet the needs of the majority of estates.

In LAPS you can just choose to manage the Built-in Local Administrator account regardless of what it is has been renamed to by leaving the Group Policy setting as Not Configured. This is easiest.

If however you need to manage non-Built-in Local Admin accounts then you will need to ensure that all target clients have the desired admin account present and named correctly. If the name is not the same then it will not be managed by LAPS.

In this scenario we need list all members of the local Administrators groups on all servers and verify that the admin account is present. This can be done remotely using Powershell. Jeffery Hicks has written a script that can do this: https://jdhitsolutions.com/blog/powershell/4908/get-local-group-members-with-powershell/

12. Be Familiar With the Microsoft Documentation

Bundled with the official LAPS installer download are two very useful documents that answer many questions that a customer might have.
