How-to: ConfigMgr – Deploy Windows 10 Feature Updates with the new Servicing and Task Sequence integration

Introduction

Microsoft Endpoint Configuration Manager Current Branch 2103 now combines the ease of Windows 10 Servicing with the versatility of Task Sequences.

The Windows 10 Servicing node in ConfigMgr has been around for some time however many organisations have not been able to rely on it solely for workstation upgrades. Frequently Task Sequences need to be deployed to carry out the Feature Update in order to clean-up the workstation prior to upgrade or refresh Applications and Drivers to compatible versions.

Doing this carries a burden on the infrastructure. An entire OS image (~5.5GB for 20H2) needs to be stored on Distribution Points in addition to the OS image used for a bare metal OS deployment Task Sequence. Workstations need to download the entire package in order to upgrade. In reality, they do not need all of the files in the package because they already have many of them.

What if we could deploy only the files needed for the Feature Update and even allow clients to download them directly from Windows Update?

Well, now we can! ConfigMgr 2103 introduces integration between the Software Update Point and Task Sequences. Below we will step through how to configure this.

There is no change to the user experience whether you use an upgrade Task Sequence based on an OS image (wim) or Feature Update (esd) file.

Pre-requisites

  • A Software Update Point must be configured in the Configuration Manager environment.
  • The SUP must be configured to download the Upgrade classification for the product Windows 10, version 1903 and later.
  • The SUP must be syncing the same language updates as the workstations that will be targeted for upgrade.

Basic Upgrade Task Sequence

The first thing you may think is that we can simply create a new task Sequence and select a new option in the wizard. Nope, sorry!

We must create a custom Task Sequence and add an upgrade step (or modify an upgrade template from the wizard but more on that later). To do this, open the ConfigMgr console:

Go to Software Library > Operating Systems > Task Sequences > Right click Task Sequences and select Create Task Sequence.

Select Create a new custom task sequence

Give the Task Sequence a Name. Do not attach a Boot image. Optionally select Run as high performance power plan.

Next to create the empty Task Sequence.

Navigate to the new Task Sequence and edit it to open the editor.

Select Add > Images > Upgrade Operating System

On the right, select Install the following feature updates and click the sun symbol.

Expand Classifications > Upgrades > Microsoft > Windows 10, version 1903 and later

Select the version and language you wish to deploy. In this instance it is business editions, 20H2 en-gb x64.

Next go to Add > General > Restart Computer

On the right under Specify what to run after restart: select The currently installed default operating system.

Select OK. That is the all we need to create a basic Task Sequence that will upgrade Windows 10 to 20H2.

This post will not cover all the steps of deploying a Task Sequence except to highlight that when you deploy the new Task Sequence you will find an additional item in the wizard called Deployment Package.

If you have deployed Software Updates from ConfigMgr then you will be familiar with this tab. This appears because we are making use of ConfigMgr’s Windows 10 Servicing components. Here we select which Deployment Package we want to download the update to or we can create a new one.

Note: If you have already downloaded the Feature Update to a Deployment Package then you are not presented with the Deployment Package tab in the wizard.

At the bottom you can select not to use a Deployment Package. Doing this means the client will use peers (if configured in the environment) or the internet based Windows Update service to download the Feature Update file. VPN clients with split tunnels for internet access may be a good target for such a configuration.

Testing the Deployment

In the lab we have a Windows 10 1909 Enterprise x64 client that I have deployed a 20H2 Task Sequence upgrade to as an Available deployment. I selected the option for no deployment package so that the client downloads the update from the internet.

In Software Center we see the Task Sequence.

We select to install. The Task Sequence runs just like a normal upgrade Task Sequence.

In the client’s ContentTransferManager.log we see the below line confirming that it has started downloading the .esd Feature Update file from Microsoft.

The .esd file is ~3.8GB. This is 30% less than the 5.5GB image we would have had to use in the old Task Sequence upgrade method.

After the install the device restarted as part of the Task Sequence steps we configured. We now see version 20H2 is now running on the device.

Advanced Task Sequence

A more realistic Task Sequence for upgrade has a number of pre and post actions. This new way of delivering the .esd file can be piggybacked on to the template that Microsoft provide.

To do this you must already have an Operating System Upgrade image saved in ConfigMgr. It can be for any Feature Update version as we only need it to complete the wizard as you will see below.

Go to Software Library > Operating Systems > Task Sequences > Right click Task Sequences and select Create Task Sequence > Upgrade an operating system from an upgrade package

Give the Task Sequence a Name. Optionally select Run as high performance power plan.

On the Upgrade Package tab, select any Upgrade Package that is already in the environment. Don’t worry about the Edition index, just select Next.

Next all the way through and create the Task Sequence. Once created, edit the Task Sequence to display the editor.

Select the Upgrade Operating System step and change it to Install the following feature updates and click the sun symbol.

Expand Classifications > Upgrades > Microsoft > Windows 10, version 1903 and later

Select the version and language you wish to deploy. In this instance it is business editions, 20H2 en-gb x64.

Now we have an advanced template to build out all the steps we need.

Summary

The integration of Windows 10 Servicing components presents options for reducing the overall footprint of Feature Updates on a network. Previously, to reduce this required separating the advanced capabilities of Task Sequences from the actual upgrade delivered by Windows 10 Servicing.

Clients can now connect directly to Windows Update to download the Feature Update file for a Task Sequence upgrade rather than rely on the Distribution Points or a CDP enabled Cloud Management Gateway (the latter of which can incur costs).

How-to: Desktop Analytics – Export list of devices a given Application or Driver is installed on

Desktop Analytics is now available in Public Preview - Microsoft Tech  Community

Introduction

Desktop Analytics is a powerful tool for helping plan deployments of Windows 10 Feature Updates. Two of its features are the Apps and Drivers tabs which provides cloud enabled insights in to your Application and Driver estate and its compatibility with Windows 10 Feature Updates.

The Apps tab has a Plan Installs column which tells you how many devices the particular Application is installed on. Similarly, the Drivers tab has a Plan Devices column which does the same.

One of the shortcomings of the Desktop Analytics console is that although it tells you how many devices have an Application or Driver , you cannot drill down further to get a list of those devices. Being able to view the list of devices without having to run a report in ConfigMgr is a challenge that I recently encountered.

In steps Log Analytics workspace queries! Desktop Analytics stores its data in a Log Analytics workspace. Using the query language Kusto (KQL) we can search the database directly and export lists of devices. Below I have shared the scripts I wrote to do this along with explanations of what they are doing.

Skip to the end of this post if you just want to see the scripts in their entirety.

Pre-requisites

  • Ability to run queries in the Log Analytics workspace in which Desktop Analytics resides.
  • Access to the Desktop Analytics console.

Prepare

1. Get the exact wording for the search terms

First go to the Desktop Analytics console and drill down in to your Deployment Plan > Plan assets > Apps.

Select the Application that you want to report on from the list. In this example I want Adobe Acrobat Reader DC version 21.001.20145.

Copy the exact wording of the name and version number. We will use this in the script query.

If you are searching for a Driver then you go to Deployment Plan > Plan assets > Drivers.

Select the Driver that you want to report on from the list. In this example I want the HP HD Camera Driver spuvcbv64.sys version 3.7.8.5.

Again, ensure to copy the exact wording of the name and version number.

2. Open a Log Analytics workspace query

Navigate to the Log Analytics workspace that contains the Desktop Analytics data. On the left hand menu select Logs.

You should see a blank New Query 1 window (you may have to close the Queries popup to see this).

The scripts use tables in the Microsoft365Analytics sphere. If you expand this on the left you will see all the available tables.

Tip: Double clicking a table will add it to the query pane. Select Run with just the name of a table in the query pane and you will see all the data in the table.

Scripts Deep Dive

Tip: Desktop Analytics takes a data scrape from Microsoft’s central Telemetry repository once every 24 hours. The historical data is left in the tables. So when searching a table be sure to filter by the last 24 hours to prevent duplication of results!

Applications

There are three sections to this code that deal with each table it needs to work through to find the device names from a given Application name.

Part 1

Creates a variable named AppProgID.

Searches the MAApplication table for the Application name and version number. Filter on the most recent data scrape (last day) and extract only the unique ProgramID. There is one ProgramID per Application/Version pairing so each version of Adobe Acrobat Reader DC has its own unique ProgramID.

Tip: You can leave the AppVersion field empty if you are searching for an Application that Desktop Analytics has not detected the version of. You will encounter these In the DA console, the version field is blank.

Part 2

Another variable is created called Devices. Searches the ProgramID column of the MAApplicationInstance table for entries matching the ProgramID stored in the AppProgID variable.

Filters for the most recent data scrape (last day) and extracts the unique device ID. These IDs are meaningless outside of Desktop Analytics so we need to convert these to the device names.

Search the DeviceID column in the MADevice table for anything matching entries in the Devices variable. Filters for the most recent data scrape (last day) and extracts a useful set of information about the devices.

You can export this list to CSV by clicking Export at the top of the Query pane.

Drivers

Due to a difference in the way the data is stored in the tables there are only two parts to this script.

Part 1

Creates a variable named DeviceID.

Searches the MADriverInstanceReadiness table for the Driver name and version number. Filters on the most recent data scrape (last day) and extracts only the unique DeviceID of all devices that have the Driver installed.

Tip: You can leave the DriverVersion field empty if you are searching for a Driver that Desktop Analytics has not detected the version of. You will encounter these in the DA console, the version field is blank.

Search the DeviceID column in the MADevice table for anything matching entries in the DeviceID variable. Filters for the most recent data scrape (last day) and extracts a useful set of information about the devices.

You can export this list to CSV by clicking Export at the top of the Query pane.

Scripts In Full

Applications

// Desktop Analytics: List workstations with a particular
// Application installed.
// Author: Marcus Zvimba, 28th April 2021
//
/////// INSTRUCTIONS
// Replace the text in the speech marks after AppName and AppVersion with the name and
// version of the Application as it appears in the Desktop Analytics console.
// The text is not case sensitive.
//

//Get ProgramID
let AppProgID =
    MAApplication
    | where AppName =~ "Adobe Acrobat Reader DC"
    | where AppVersion =~ "21.001.20145"
    | where TimeGenerated > ago(1d)
    | project ProgramId;
//Get Device IDs
let Devices =
    MAApplicationInstance
    | where ProgramID in (AppProgID)
    | where TimeGenerated > ago(1d)
    | project DeviceId;
//Get Device Names
MADevice
| where DeviceId in (Devices)
| where TimeGenerated > ago(1d)
| project DeviceName, DeviceId, DeviceLastSeenDate, Manufacturer, Model, OSVersion, OSEdition, OSBuildNumber, OSArchitecture

Drivers

// Desktop Analytics: List workstations with a particular
// driver installed.
// Author: Marcus Zvimba, 28th April 2021
//
/////// INSTRUCTIONS
// Replace the text in the speech marks after DriverName and DriverVersion with the name and
// version of the driver as it appears in the Desktop Analytics console.
// The text is not case sensitive.
//

//Get DeviceID
let DeviceID =
    MADriverInstanceReadiness
    | where DriverName =~ "spuvcbv64.sys"
    | where DriverVersion =~ "3.7.8.5"
    | where TimeGenerated > ago(1d)
    | project DeviceId;
//Get Device Names
MADevice
| where DeviceId in (DeviceID)
| where TimeGenerated > ago(1d)
| project DeviceName, DeviceId, DeviceLastSeenDate, Manufacturer, Model, OSVersion, OSEdition, OSBuildNumber, OSArchitecture

Summary

Kusto is a powerful language and once the core concepts are understood it can be leveraged to maximise the data available from Desktop Analytics. You can create graphical reports to compliment the built-in reports in the Desktop Analytics console.

There is not much movement from Microsoft on the Desktop Analytics UserVoice forum so I highly recommend becoming familiar with how to query the data directly.

Microsoft Local Administrator Password Solution – Part 4 – Auditing

LAPS is a fantastic free tool from Microsoft that manages Domain Member computer local account passwords. https://www.microsoft.com/en-us/download/details.aspx?id=46899

I have deployed LAPS for a number of Enterprise customers to use for managing their Domain Member Windows Server local Administrator account passwords.

In the final part of this blog series we will look at how to audit LAPS password access.

Part 1 of this blog series “Deployment Considerations”

Part 2 of this blog series “Accessing and Resetting Passwords”

Part 3 of this blog series “Monitoring”

Auditing LAPS

LAPS generated passwords are stored on the Active Directory Computer Object in the attribute ms-Mcs-AdmPwd.

By default, when a principal with the AD permission Read ms-Mcs-AdmPwd reads the attribute ms-Mcs-AdmPwd there is no log entry made on the Domain Controller. Therefore, a compromised account could dump all LAPS set passwords from AD undetected.

We can configure auditing within Active Directory. The LAPS Powershell module allows us to easily do this.

In the example below, Auditing is enabled for the Member Servers Organisational Unit.

Import-Module AdmPwd.PS
Set-AdmPwdAuditing -OrgUnit "OU=Member Servers,DC=lab,DC=home" `
-AuditedPrincipals:Everyone
Auditing applied to OU

All Computer Objects in the Member Server OU will now be audited for LAPS password reads.

Event ID 4662 is logged in the Domain Controller Security event log every time the password attribute (ms-Mcs-AdmPwd) is read. Which Domain Controller it is logged on depends on which Domain Controller the request is sent to by the client requesting it.

Powershell retrieval of the password triggers event ID 4662 on the Domain Controller

The log entries can be parsed using a combination of the event ID and the schemaIDGUID for the attribute ms-Mcs-AdmPwd (which is unique to each AD Forest).

The three key items in the event are:

  • Security ID (account that read the password)
  • Object Name (Distinguished Name of the computer whose password was read)
  • schemaIDGUID (Identifier for the password attribute)

Finding the SchemaIDGUID

These instructions use a slightly modified version of the answer given by Mathias R Jessen on Stackoverflow.

Run the below Powershell command from a device with the Active Directory Powershell module installed to extract the schemaIDGUID for the attribute ms-Mcs-AdmPwd.

$attrSchemaParams = @{
    SearchBase = (Get-ADRootDSE).schemaNamingContext
    Filter = "ldapDisplayName -eq 'ms-Mcs-AdmPwd' -and objectClass -eq 'attributeSchema'"
    Properties = 'schemaIDGUID'
}
$LAPSschema = Get-ADObject @attrSchemaParams

$LAPSschemaPwdGUID = $LAPSschema.schemaIDGuid -as [guid]
$LAPSschemaPwdGUID
Powershell script output

REMEMBER: This Guid is unique for each AD Forest.

Looking closer at the Event ID 4662 that was logged when we read the password, we can see the same GUID under “Properties:“.

Unique schemaIDGUID

A log monitoring tool can be configured to search for:

  • Targets: Domain Controllers
  • EventID: 4662
  • Keywords: < Unique schemaIDGUID >

Microsoft Local Administrator Password Solution – Part 3 – Monitoring

LAPS is a fantastic free tool from Microsoft that manages Domain Member computer local account passwords. https://www.microsoft.com/en-us/download/details.aspx?id=46899

I have deployed LAPS for a number of Enterprise customers to use for managing their Domain Member Windows Server local Administrator account passwords.

In part 3 of this blog series we will look at how to monitor LAPS operations.

Part 1 of this blog series “Deployment Considerations”

Part 2 of this blog series “Accessing and Resetting Passwords”

Part 4 of this blog series “Auditing”

The LAPS Process

LAPS is a Client Side Extension for Group Policy. LAPS is triggered each time Group Policy is refreshed on a device. This means you will not find it in Windows Services nor running as a process in Task Manager.

When LAPS is triggered, it checks the attribute ms-Mcs-AdmPwdExpirationTime on the host device’s Active Directory Computer Object. If this attribute has no value or is a date and time in the past then LAPS will attempt to set a new password.

First it will attempt to write the password to the attribute ms-Mcs-AdmPwd on the host device’s AD Computer Object. Once it confirms it has been successfully written to AD, LAPS updates the password on the host device (writes the password to the local Security Account Manager database).

  • LAPS will only set a new password if a Domain Controller is accessible after a new password has been generated. This ensures that AD always has the current password.

Monitoring LAPS

LAPS logs to the Application event log with the source AdmPwd. By default, LAPS only logs errors.

The logging level is set by the registry key below:

HKLM\SOFTWARE\Microsoft\Windows NT\CurrentVersion\Winlogon\GPExtensions{D76B9641-3288-4f75-942D-087DE603E3EA}\ExtensionDebugLevel REG_DWORD

ValueMeaning
0Silent mode; log errors only
When no error occurs, no information is logged about CSE activity
This is a default value
1Log errors and warnings
2Verbose mode, log everything

A full list of the possible log entries are in the document LAPS_TechnicalSpecification.docx which is included with the official LAPS download.

Setting the log entries to a value of 1 should suffice for most environments. Your existing monitoring solution may be able to be configured to generate alerts based on the Event Log entries from LAPS.

Logging Demonstration

The host LAB-CTXHOST has had LAPS installed. It has a GPO applied that sets LAPS to verbose logging by creating the below registry key:

HKLM\SOFTWARE\Microsoft\Windows NT\CurrentVersion\Winlogon\GPExtensions{D76B9641-3288-4f75-942D-087DE603E3EA}\

ExtensionDebugLevel

Type: REG_DWORD

Value: 2

LAPS Verbose logging

On LAB-CTXHOST using RegEdit we can see that the registry key has been created.

RegEdit

In Windows Event Log, we have filtered the log to only show events from the source AdmPwd.

Application event log filter

Logging Demo: Password Change Not Required

Now we force a Group Policy update by running gpupdate from the command line.

gpupdate

When we refresh the event log, we see event IDs 15, 11 then 14.

Event ID 15: Start of processing LAPS
Event ID 11: LAPS logic
Event ID 14: End of processing LAPS

Reading the events we can see that LAPS took no action because the password expiration date and time on the AD Computer Object for LAB-CTXHOST is 30 days in the future.

Logging Demo: Password Change Required

Using Powershell, we set the expiration date to be in the past. Now we run gpupdate and observe the log entries.

This time we see event IDs 15, 5, 13, 12 then 14.

Event ID 15: Start of processing LAPS
Event ID 5: LAPS has generated a new password and validated it against the GPO controlled password requirements.
Event ID 13: New password successfully written to Active Directory.
Event ID 12: New password successfully updated on the local administrator account.
Event ID 14: End of processing LAPS

Logging Demo: No Domain Controller Available

If the Domain Controller is inaccessible at the start of Group Policy processing, no LAPS log entries will appear. This is because Group Policy processing fails before the LAPS Group Policy Client Side Extension is triggered. LAPS will never reset the password under these conditions.

Logging Demo: No permission over object

During the installation of LAPS, we use the Set-AdmPwdComputerSelfPermission LAPS Powershell module cmdlet to apply the following permission to the Organisational Unit that contains the Computer Objects that are due to receive LAPS.

  • Principal: SELF
  • Permission: Write ms-Mcs-AdmPwd
  • Applies to: Descendent Computer Objects

This allows the devices to update their passwords in Active Directory.

We have now removed this permission for LAB-CTXHOST and used the LAPS Powershell module cmdlet Reset-AdmPwdPassword to set an expiration date and time that is in the past.

After running gpupdate we see the event IDs 15, 5 and 7.

Event ID 15: Begin processing LAPS
Event ID 5: LAPS has generated a new password and validated it against the GPO controlled password requirements.
Event ID 7: LAPS fails to write the password to AD

Summary

We have seen that using the Windows Event Log, we can view to a granular level which step of the LAPS process has failed. In production, logging level 1 (Errors and Warnings) should suffice and most monitoring solutions can be configured to read these logs entries and generate alerts.

Microsoft Local Administrator Password Solution – Part 2 – Accessing & Resetting Passwords

LAPS is a fantastic free tool from Microsoft that manages Domain Member computer local account passwords. https://www.microsoft.com/en-us/download/details.aspx?id=46899

I have deployed LAPS for a number of Enterprise customers to use for managing their Domain Member Windows Server local Administrator account passwords.

In Part 2 of this blog series we will look at the different ways to view and reset the passwords.

Part 1 of this blog series “Deployment Considerations”

Part 3 of this blog series “Monitoring”

Part 4 of this blog series “Auditing” [Coming Soon]

Key Points

  • To view the LAPS passwords, you must be granted the All Extended Attributes permission over the object in Active Directory.
  • If the Group Policy setting “Do not allow password expiration time longer than required by policy” is set to Enabled; it will not be possible to set an expiry beyond the maximum LAPS Password Age Group Policy setting.

Graphical User Interface

When you install LAPS you are given the option of Management Tools to install.

LAPS Setup Options

The Fat client UI will install a simple app called AdmPwd.UI to the default install location %SYSTEMDRIVE%\Program Files\LAPS

When launched you can search for the computer name. The password will displayed along with the password expiration date.

Fat client UI

To manually reset the password, just click the Set button in LAPS UI tool. When a Group Policy refresh runs on the target machine, the password will be reset.

You can set a future date for the password to expire by clicking the drop down icon on the New expiration time field.

Powershell

When you install LAPS you are given the option of installing the Powershell Module.

Powershell module install

From a Powershell prompt, run the following commands to retrieve a LAPS password:

Import-Module AdmPwd.PS
Get-AdmPwdPassword -ComputerName "computername"

Retrieving the LAPS password using Powershell

To set a new expiration time, run the following commands:

Import-Module AdmPwd.PS
Reset-AdmPwdPassword -ComputerName "computername" `
-WhenEffective "date time"

In the example below the password is being set to expire on 30th November 2019 at 10am.

By using Get-AdmPassword we can confirm that ExpirationTimestamp attribute has been updated.

When the server refreshes its GPO after 30th November 10am, it will read the expiration attribute and trigger

  • The password only resets if the client is able to write the new password to the AD computer object.
  • If the client does not have permission to do this or a Domain Controller cannot be contacted at that time then the new password is discarded before it is applied to the local admin account.
  • Writing the password to AD before the password is written to the local admin account protects against network interruptions during the process.

ADSI Edit

1. On any Domain Controller (or console running Active Directory Remote Server Administration Tools) open ADSI Edit by Right clicking the Start button and select Run.

2. Enter ADSIEdit.msc and select OK.

Run ADSIEdit.msc

3. Right click ADSI Edit in the left hand menu and select Connect to. Choose the Default Naming Context.

Connect to Default naming context

4. On the left, navigate down through the Active Directory structure by double clicking.

5. Browse to the client’s object, right click it and select properties.

Computer object

6. On the Attribute Editor tab, scroll to the attributes:

Password attribute

ms-Mcs-AdmPwd – Stores the password in clear text

ms-Mcs-AdmPwdExpirationTime – Stores the time to reset the password

  • The expiration time is displayed in computer date format. It must be manually converted to a readable date format.
  • You can set the expiration time here by converting the desired date back to computer date format and editing the attribute within ADSIEdit.

Microsoft Local Administrator Password Solution – Part 1 – Deployment Considerations

LAPS is a fantastic free tool from Microsoft that manages Domain Member computer local account passwords. https://www.microsoft.com/en-us/download/details.aspx?id=46899

I have deployed LAPS for a number of Enterprise customers to use for managing their Domain Member Windows Server local Administrator account passwords.

In Part 1 of this blog series we will run through some of the prerequisite checks that I perform when asked to deploy LAPS.

Part 2 of this blog series “Accessing & Resetting Passwords”

Part 3 of this blog series “Monitoring”

Part 4 of this blog series “Auditing”

This post is written assuming that we have already read the installation instructions for LAPS. The list does not have to be done sequentially. Although this post is written with Server deployments in mind, the same considerations apply to Workstation deployments.

1. Nominate a management host

Nominate a device on which we will install the LAPS management tools. I normally do this on a management server which will eventually be used to run the LAPS GUI and Powershell module from by administrators. The device must have at least .NET 4.0 and Powershell 2.0.

This can of course be installed on workstations too. In the real world though many enterprises have management servers from which most admin tasks are done.

2. Nominate a test server

This is for testing the LAPS Client Side Extension and GPO. Recommended to be a Virtual Machine on which snapshots/checkpoints can be taken. Should be a non-critical server that we can reboot multiple times.

3. List the Distinguished Names of all Organisational Units that contain the target Member Servers

Typically customers will create an Organisational Unit branch called “Servers” under which they will store all of their server computer accounts. Sometimes there are servers elsewhere so it’s always good to check so that we can target all Servers with a GPO. Get all the servers not in the expected Organisational Unit branch.

In the code snippet, change the “*OU=Servers..” etc. to be the distinguished name of the OU under which the majority of the server computer accounts are.

$computers = Get-adcomputer -filter * -Properties *
$computers | ?{$_.operatingsystem -like "*Server*" -and `
$_.distinguishedname -notlike "*OU=Servers,DC=Domain,DC=com*"}

4. Identify accounts with ‘All Extended Rights’ permission

LAPS passwords are stored on the Active Directory computer object. To view the passwords a user must have the ‘All extended rights’ permission.

By default only SYSTEM and Domain Admins have this permission. It is rare that other users will have been added, however, we should check for anyone who already has this permission so that we do not inadvertently grant unauthorised users access to the new local admin passwords.

In step 3, we created a list of Organisational Units that contain all the Windows Servers that we will target with LAPS. We will now produce a list of users that have the ‘All Extended rights’ permission over these Organisational Units.

The LAPS Powershell module that is installed when you do a Full install of the LAPS client comes with a useful function to do this: Find-AdmPwdExtendedRights

The below script feeds the list of OUs ‘ListOfOU.txt’ in to to the function and creates a list of permission holders per OU.

Import-Module AdmPwd.PS
$list = Get-content ".ListOfOU.txt"
foreach($_ in $list){Find-AdmPwdExtendedRights -id "$_" `
-SchemaNotUpdated | select ObjectDN, `
@{Name=’ExtendedRightHolders’;Expression={[string]::join(“;”, `
($_.ExtendedRightHolders))}}}
Example output for ExtendedRightHolders

If any objects other than SYSTEM or Domain Admins appear in the ExtendedRightHolders column then these questions need to be answered:

a) do those objects still require the All Extended Rights permission?

b) are they authorised to be able to view passwords?

5. List of Security Principals that will have access to the LAPS passwords

An important discussion that needs to be had is “Who do you want to have access to local admin passwords?”

Too many organisations have nested Active Directory Security Groups that have inadvertently given junior IT staff Domain Admin rights. This is an ideal time to review this within your organisation or with your customer.

You can grant additional security groups the “All Extended Rights” attribute so that they do not need to have Domain Admin rights.

6. Reboot Schedule

Many Enterprises do not use SCCM to manage their Servers. Another way to deploy the LAPS installer is using Group Policy Software Installation. A draw back of this is that the client machine needs to restart in order for LAPS to install during startup.

To minimise disruption, it may be beneficial to apply the Group Policy at the start of the monthly Windows Security updates schedule and take advantage of the already agreed reboot schedules for servers.

7. Active Directory Replication

One part of deploying LAPS is extending the Active Directory Schema to add the password and password expiration date attributes to computer objects. This relies on AD replication being functional.

We can save ourselves a lot of headache during a Change Request window if we check AD replication health prior to the deployment

repadmin /replsummary
repadmin /replsummary command output

In the green box is the largest time since the last replication for all links on the listed outbound (top) or inbound (bottom) server. If any of these are in multiples of hours then there may be a replication problem.

In the pink box; if there are any failures then there is definitely a replication problem.

We must resolve issues with AD replication before we start implementing LAPS.

8. Identify Read Only Domain Controllers

The two attributes that are added when LAPS extends the Active Directory schema are:

ms-Mcs-AdmPwdStores the password in clear text
ms-Mcs-AdmPwdExpirationTimeStores the time to reset the password

By default the ms-Mcs-AdmPwd attribute is on the Filtered Attribute Set for Read Only Domain Controllers. This means that it is not replicated to RODCs. IT will not be able to retrieve LAPS passwords from the RODC.

There is logic to this, RODCs are typically located in branch locations classed as insecure. They may be behind a locked door but that door could be cupboard on the ground floor and is accessed by many non-IT staff. It must be assumed that that the RODC may one day be stolen and so we want to minimise the impact should this occur.

Do we really want the RODC to store all of the local admin passwords for all of the Servers on the network?

Nevertheless, there may be a need to replicate this attribute to RODCs. Russell Smith has an excellent blog post on how to do this: https://www.petri.com/modify-the-read-only-domain-controller-filtered-attribute-set-using-adsi-edit

To identify if any RODCs exist in the domain, run the below command:

Get-ADDomainController -Filter {IsReadOnly -eq $true}

9. Schema Admin Rights

To be able to extent the Active Directory Schema we need Schema Admin Rights. In a tightly controlled environment we need to get the request for these rights in early. No Schema Admin, no LAPS.

11. Name of Local Administrator account

Some organisations have multiple local admin accounts on a server.

  • You can only manage one account per server per policy.
  • One device can only be managed by one policy.

We should look to reduce the number of local admin accounts in use on the estate in favour of Domain User and Service Accounts with Role Based Access Control. A single local admin account can meet the needs of the majority of estates.

In LAPS you can just choose to manage the Built-in Local Administrator account regardless of what it is has been renamed to by leaving the Group Policy setting as Not Configured. This is easiest.

If however you need to manage non-Built-in Local Admin accounts then you will need to ensure that all target clients have the desired admin account present and named correctly. If the name is not the same then it will not be managed by LAPS.

In this scenario we need list all members of the local Administrators groups on all servers and verify that the admin account is present. This can be done remotely using Powershell. Jeffery Hicks has written a script that can do this: https://jdhitsolutions.com/blog/powershell/4908/get-local-group-members-with-powershell/

12. Be Familiar With the Microsoft Documentation

Bundled with the official LAPS installer download are two very useful documents that answer many questions that a customer might have.

Device loses domain connectivity due to UDP port exhaustion

Symptoms

A Windows Server initially reported as Group Policy failing to update. Further investigation found that the server was unable to resolve the domain name despite having no firewall blocking traffic and having the correct DNS servers configured. Common troubleshooting tools such as Netdom and NSLookup were also failing. Some network traffic was working however.

The server had last restarted 6 months before and the issue had started 2 months after that. For now let’s ignore the elephant in the room of why it had taken 4 months for the issue to be noticed.

Solution

The failing tools all related to UDP traffic.

Running “Netstat –ano –p UDP” showed that all dynamic UDP ports 49152 to 65535 were being used by one process, “Cisco Presence Server Plug-in.exe”. This was UDP port exhaustion. No other service was able to use the UDP dynamic port range which effectively blocked the server from communicating with the domain.

Restarting the server cleared the exhausted ports and the application owner was requested to raise this behaviour with the vendor.

GoToMeeting Launcher error 1392

When running the Go To Meeting test session from here I got an error code of 1392. When opening the log below I saw the following:

08:43:56 2CC8 I: created file ‘C:\Users\username\AppData\Local\Temp\26\B0560F7D-757E-4C65-A168-2364C6F4606F\G2MCoreInstExtractor.exe’

08:43:56 2CC8 E: Installer launch failed; command was: “C:\Users\username\AppData\Local\Temp\26\B0560F7D-757E-4C65-A168-2364C6F4606F\G2MCoreInstExtractor.exe” “/Action Join” “/EGWAddress 216.115.208.230” “/EGWDNS egwglobal.gotomeeting.com” “/EGWPort 80,443,8200” “/MeetingID 333699349” “/Mode Terse” “/Product g2m” “/colClientUiReadyEvent Global\BC84F869-6926-4A19-9926-7111917D85E8” “/sessionTrackingId ul-0396-0714-9b0e-beb9799efb97”
08:43:56 2CC8 E: [installEndpoint] completed: 2001 (ECError::eSomeError), Method “CreateProcess” returned Win32 error [1392]. The file or directory is corrupted and unreadable.

From what I could see, the launcher had two stages. The first was to download
G2MCoreInstExtractor.exe.

08:43:56     2CC8 I: created file 'C:\Users\username\AppData\Local\Temp\26\B0560F7D-757E-4C65-A168-2364C6F4606F\G2MCoreInstExtractor.exe'

The second would launch that to download the remaining files. This is where it appeared to be failing.

 Installer launch failed; command was: "C:\Users\username\AppData\Local\Temp\26\B0560F7D-757E-4C65-A168-2364C6F4606F\G2MCoreInstExtractor.exe"

The issue was not that it was failing to launch but that it was failing to download in the first place. The proxy server had an ‘allow .EXE file downloads’ set for GoToMeeting.com but not for the GetGo Content Distribution Network which hosts the file G2MCoreInstExtractor.exe. Adding the GetGo URLs that host the GoToMeeting file to the allow list resolved this:

getgo.com:443/builds/g2m/
getgocdn.com:443/builds/g2m/
getgo.com/builds/g2m/
getgocdn.com/builds/g2m/

Intune Windows 10 Autopilot deployment profile MENU BUG – Don’t be caught out!

Microsoft recently released two hotly anticipated Intune Preview features:

  • Self-Deploying Autopilot – Azure AD Joined
  • User-Driven Autopilot – Hybrid Azure AD Joined

Naturally Microsoft has added logic to the menu selections in the Autopilot Deployment Profiles that greys out incompatible menu options. I have found and reported to Microsoft a bug that allows you to select incompatible options. Doing so causes you Autopilots to fail.

Creating a new policy and selecting Deployment mode: User-Driven Autopilot – gives you two options:

  • Azure AD Join
  • Hybrid Azure AD Joined (Preview)

Selecting Self-Deploying (Preview) locks the ‘Join to Azure AD as’ drop down menu on to Azure AD Joined. This is desired because Hybrid Azure AD Join is not available for Self-Deploying mode (yet).

Now the bug…

  1. Save a policy with the User-Driven – Hybrid Azure AD Joined options selected.
  2. Go back in to the policy and select Properties.
  3. Change the Deployment Mode to “Self-Deploying”.
  4. Note that the ‘Join to Azure AD as’ drop down stays greyed out on the invalid option ‘Hybrid Azure AD Joined’ .

The impact…

This is not just cosmetic. By doing this the Autopilot device will fail on the Enrolment Status Page (ESP) with the error: 0x801c03ed.

Windows 10 AutoPilot Error 80004005

During Windows AutoPilot in User Driven mode you may see the following error on the Network tab (after Windows has downloaded the AutoPilot profile but before the reboot). It takes about 10-20 minutes for this error to display.

Something went wrong.
Confirm that you are using the correct sign-in information and that your
organisation uses this feature. You can try to do this again or contact
your system administrator with the error code 80004005
36,35,305,312.797363

Check that the device has a clear line of sight to to a Domain Controller. This is a requirement of User-Driven Autopilot.
